Series Specs
PM 2821 | PM 2822 | PM 2823 | |
|---|---|---|---|
| Spec Sheet | |||
| Spec Sheet | - | - | - |
| Max. Pressure | - | - | - |
| Fuel Tank Capacity | - | - | - |
| Max. Lifting Moment | 18230 ft Ibs | 17540 ft Ibs | 17210 ft Ibs |
| Hydraulic Horizontal Outreach | 15′ 55” | 20′ 0” | 24′ 7” |
| Hydraulic Vertical Outreach | 24′ 7” | 28′ 10” | 33′ 2” |
| Recommended oil flow | - | - | - |
| Slewing torque | - | - | - |
| Stabilizer Spread available | - | - | - |
| Slewing angle | 360° | 360° | 360° |
| Stabilizer control Radio Wireless | Manual | Manual | Manual |
| Width | 1′ 8” | 1′ 8” | 1′ 8” |
| Height | 5′ 1” | 5′ 1” | 5′ 1” |
| Length | 5′ 11” | 5′ 11” | 5′ 11” |
Vehicle Type
Equipment
External mechanical slewing limiter
Standard
Manual flip-up outriggers
Standard
Manual pull-out outrigger booms
Standard
Rack
Standard
Safety Kit for outriggers
Standard
A
Air/oil heat exchanger
Optional
Hose reel
Optional
Tank
Optional
Air Oil Heat Exchanger
Standard
