Series Specs
PM 3921 P | PM 3922 P | PM 3923 P | |
|---|---|---|---|
| Spec Sheet | |||
| Spec Sheet | - | - | - |
| Max. Pressure | - | - | - |
| Fuel Tank Capacity | - | - | - |
| Max. Lifting Moment | 22130 ft lbs | 21960 ft lbs | 21570 ft lbs |
| Hydraulic Horizontal Outreach | 16′ 1″ | 20′ 8″ | 25′ 1″ |
| Hydraulic Vertical Outreach | 25′ 3″ | 29′ 6″ | 33′ 8″ |
| Recommended oil flow | - | - | - |
| Slewing torque | - | - | - |
| Stabilizer Spread available | - | - | - |
| Slewing angle | 360° | 360° | 360° |
| Stabilizer control Radio Wireless | Manual | Manual | Manual |
| Width | 1′ 8″ | 1′ 8″ | 1′ 8″ |
| Height | 5′ 3″ | 5′ 3″ | 5′ 3″ |
| Length | 6′ 2″ | 6′ 2″ | 6′ 2″ |
Vehicle Type
Equipment
External mechanical slewing limiter
Standard
Manual flip-up outriggers
Standard
Manual pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Rack
Standard
Safety Kit for outriggers
Standard
A
Air/oil heat exchanger
Optional
Hose reel
Optional
Tank
Optional
Air Oil Heat Exchanger
Standard
