Series Specs
PM 5021 P | PM 5022 P | PM 5023 P | PM 5024 P | |
|---|---|---|---|---|
| Spec Sheet | ||||
| Spec Sheet | - | - | - | - |
| Max. Pressure | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - |
| Max. Lifting Moment | 33970 ft lbs | 30110 ft lbs | 27860 ft lbs | 26310 ft lbs |
| Hydraulic Horizontal Outreach | 16′ 5″ | 20′ 12″ | 25′ 3″ | 29′ 4″ |
| Hydraulic Vertical Outreach | 25′ 7″ | 30′ 0″ | 34′ 1″ | 38′ 3″ |
| Recommended oil flow | - | - | - | - |
| Slewing torque | - | - | - | - |
| Stabilizer Spread available | - | - | - | - |
| Slewing angle | 360° | 360° | 360° | 360° |
| Stabilizer control Radio Wireless | Manual | Manual | Manual | Manual |
| Width | 2′ | 2′ | 2′ | 2′ |
| Height | 6′ | 6′ | 6′ | 6′ |
| Length | 6′ 8″ | 6′ 8″ | 6′ 10″ | 7′ 1″ |
Vehicle Type
Equipment
Manual flip-up outriggers
Standard
Manual pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Rack
Standard
Safety Kit for outriggers
Standard
A
Air/oil heat exchanger
Optional
Electro-hydraulic slewing limiter
Optional
Hose racks
Optional
LMU CE control system for mechanical extensions
Optional
Manual extensions
Optional
Tank
Optional
Air Oil Heat Exchanger
Standard
